SVC SERIES DISPENSERS
SVC SERIES DISPENSERS
SVC Series Dispensers are designed to optimize the dispensing of adhesives, lubricants and other assembly fluids by increasing throughput, improving yields and reducing production costs.
SVC720V - Consistent, precise volume control for high precision dispensing valves
SVC620S - All digital display ensures versatility and flexibility for precise spray control
SVC620CD- Non-contact dot, spray line dispensing can be selected
SVC720F - Fast response pneumatic solenoid maximizes dispensing performance
SVC620S - All digital display ensures versatility and flexibility for precise spray control
SVC620CD- Non-contact dot, spray line dispensing can be selected
SVC720F - Fast response pneumatic solenoid maximizes dispensing performance
Specification
| Input AC (to power supply) | Power supply | Air Input Requirement | Dispensing pressure setting range | Nozzle air pressure setting range | Dispensing time setting range | Cycle activation | Input or Output signal | Ambient operating conditions | Cabinet Dimensions (including protruding portion) | Weight | Accessories | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SVC720V | DC24V (AC100~240V adapter included) | 18W | 0.4MPa~0.7MPa | 0~0.50MPa( Valve operational air is more than 0.40MPa ) | - | - | Foot pedal, band switch, signal from 5VDC to 24VDC (I/O) | D-Sub9 pin connector | 5-40°C (non-condensing) | W250xD139(187)xH76(78)mm | 1.5kg | AC adapter Foot pedal switch |
| SVC620S | DC24V (AC100~240V adapter included) | 18W | 0.4MPa~0.7MPa | 0~0.50MPa( Valve operational air is more than 0.40MPa ) | 0~0.50MPa | 0.005~999.9sec | Foot pedal, band switch, signal from 5VDC to 24VDC (I/O) | D-Sub9 pin connector | 5-40°C (non-condensing) | W250xD139(187)xH76(78)mm | 1.5kg | AC adapter Foot pedal switch |
| SVC620CD | DC24V (AC100~240V adapter included) | 18W | 0.4MPa~0.7MPa | 0~0.50MPa(Valve operational air is more than 0.40MPa) | 0~0.50MPa | 0.005~999.9sec | Foot pedal, band switch, signal from 5VDC to 24VDC (I/O) | D-Sub9 pin connector | 5-40°C (non-condensing) | W250xD139(187)xH76(78)mm | 1.4g | AC adapter Foot pedal switch |
| SVC720F | DC24V (AC100~240V adapter included) | 18W | 0.4MPa~0.7MPa | 0~0.50MPa( Valve operational air is more than 0.40MPa ) | - | - | Foot pedal, band switch, signal from 5VDC to 24VDC (I/O) | D-Sub9 pin connector | 5-40°C (non-condensing) | W160xD139(176)xH76(78)mm | 0.8kg | AC adapter Foot pedal switch |
